10 Wheel Dumper
CAMC M5 10 wheel dump truck has been exported to over 60 countries and regions worldwide and enjoys a very high reputation for its performance and reliability, which has been consistently praised by customers.
CAMC Group is a professional manufacturer of commercial vehicles in China, integrating R&D, design, production, transportation and after-sales service, and accepting cooperation from other parties such as dealers and end customers.
Our global partners：
Main Specification:
Name of Product | Model | HW3250B35D1M3T-003 |
Driving model | 6X4 | |
Name of product | M5 Dump truck | |
Steering | Steering | LHD |
Engine | Model | CM6D18.385 31 |
Manufacture | CAMC | |
Max horse power | 385HP | |
Max torque/speed | 1750N.m/1100-1450rpm | |
Displacement | 9.84L | |
Emission standard | Euro-III | |
Gearbox | Model | 12JSD180T |
Manufacture | FAST | |
Numbers of forward gear | 12 | |
Axle | Model of front axle | 7.5T 7500KG |
Model of driving axle | HL300A（5.263） 16000KG | |
Tire | Model of tire | 12.00R20 |
Fuel tank | Capacity | 400L |
suspension system | Number of springs | 9/12 |
Dimension | Wheel base | 4100+1350（mm） |
Dimension | 8680*2500*3360（mm） | |
Weight | Kerb weight | 12500KG |
GVW | 25000KG | |
Body | Box dimension | 5600*2350*1500（mm） |
Hydraulic system | Front lifting / HYVA | |
Thickness | Bottom 8 side 6 | |
Style of box | Rectangular |
